GPS трекер SkyWave IDP-782 | Интегрирован с Wialon

Особенности SkyWave IDP-782:

Наличие черного ящика
Спутниковый терминал

Поддержано в Wialon:

Данные с CAN-шины
Управляющие команды по GPRS
Связь через TCP

Для того чтобы система мониторинга Wialon корректно идентифицировала данные от SkyWave IDP-782 в диалоге настроек объекта, укажите следующие данные :

Тип устройства:	SkyWave IDP-782
Уникальный ID:	serial

Укажите следующие параметры в конфигурационной программе или в конфигурации SkyWave IDP-782 для использования его в Wialon Hosting :

Порт сервера:

21211

Всего в серверном центре Wialon используется 397 объектов SkyWave IDP-782 — это составляет 0.02% от общего количества устройств в категории «Автомобильные контролеры».

График изменения количества подключений в серверном центре Wialon за последние 30 дней:

Имя параметра	Описание	Единицы измерения
hardwareVariant	This field indicates the terminal type. 1 – IDP terminal All other values are reserved
bootLoaderMajor	The major version number of the installed boot loader
bootLoaderMinor	The minor version number of the installed boot loader
bootLoaderPatch	The patch level number of the installed boot loader
firmwareMajor	The major version number of the installed base firmware
firmwareMinor	The minor version number of the installed base firmwarer
firmwarePatch	The patch level number of the installed base firmware
uptime	The number of seconds the terminal has been in continuous operation since reset
timeOfDay	The current date and time, expressed as number of seconds since the epoch
LSFUptime	The number of seconds the Lua Services Framework has been running
powerSaveTime	The number of seconds the terminal has been in power save mode since reset
sin	The SIN
enabled	Whether the service is currently enabled
proplist	A list of properties for that service
time	The new date and time, expressed as number of seconds since the epoch
extPowerPresent	external power
batteryVoltage	voltage of battery
externalVoltage	external voltage
powerOnReason	power on reason
autoPowerOnConfig	auto power on config
success	success
error	error
batteryType	Type of battery
min	min
data	The data to be sent out
fix_type	fixType
port#_cfg	Config of port where #-number of port
port#_value	value of port where #-number of port
current_temp	currentTemperature
pwr_ext	inputPowerVoltage
dte_connected	DTEConnected
cmd_success	Whether the command was successfully executed
msg_sin	sin of msg
msg_min	min of msg
region_name	name of region
ignition	1 - ignition on 0 - ignition off
comm_channel	comm_channel
event_name	name of event
gprs_channel	gprs channel

Имя параметра

Описание

Единицы измерения

hardwareVariant

This field indicates the terminal type. 1 – IDP terminal All other values are reserved

bootLoaderMajor

The major version number of the installed boot loader

bootLoaderMinor

The minor version number of the installed boot loader

bootLoaderPatch

The patch level number of the installed boot loader

firmwareMajor

The major version number of the installed base firmware

firmwareMinor

The minor version number of the installed base firmwarer

firmwarePatch

The patch level number of the installed base firmware

uptime

The number of seconds the terminal has been in continuous operation since reset

timeOfDay

The current date and time, expressed as number of seconds since the epoch

LSFUptime

The number of seconds the Lua Services Framework has been running

powerSaveTime

The number of seconds the terminal has been in power save mode since reset

sin

The SIN

enabled

Whether the service is currently enabled

proplist

A list of properties for that service

time

The new date and time, expressed as number of seconds since the epoch

extPowerPresent

external power

batteryVoltage

voltage of battery

externalVoltage

external voltage

powerOnReason

power on reason

autoPowerOnConfig

auto power on config

success

error

batteryType

Type of battery

min

data

The data to be sent out

fix_type

fixType

port#_cfg

Config of port where #-number of port

port#_value

value of port where #-number of port

current_temp

currentTemperature

pwr_ext

inputPowerVoltage

dte_connected

DTEConnected

cmd_success

Whether the command was successfully executed

msg_sin

sin of msg

msg_min

min of msg

region_name

name of region

ignition

1 - ignition on
0 - ignition off

comm_channel

event_name

name of event

gprs_channel

gprs channel
