Localizador GPS personal PL601 | Integrado con Wialon

Características PL601:

4G/LTE
Caja negra

Soportado en Wialon:

Gestión remota vía GPRS
Gestión remota vía SMS
Botón de alarma
Comunicación vía TCP
Comunicación por UDP

Para que el sistema de rastreo Wialon identifique los datos de PL601 en el diálogo de configuración de la unidad, indique los siguientes datos :

Tipo de dispositivo:	PL601
ID único:	imei

Indique los siguientes parámetros en el programa de configuración o en la configuración PL601 para utilizarlos en Wialon Hosting :

Puerto del servidor:

22873

En el centro de servicio Wialon se utilizan 0 unidades PL601 — es 0% de la cantidad total de dispositivos Personal conectados.

La gráfica representa la cantidad de conexiones en el centro de servicio Wialon en los últimos 30 días:

Nombre del parámetro	Descripción	Unidades de medida
mnc	Mobile Network Code
is_geofence_rectangular#	Circular o rectangular, 0 is circular, 1 is rectangular, where # - id
visible_sats	Visible satellites
battery_vol	Battery Voltage
alarm_status	Alarm status: 0: Normal 1: Shock Alarm 2: Power Cut Alarm 3: Low Battery Alarm 4: SOS
mileage	Mileage statistics
gsm	GSM signal strength degree
sat#_signal_strength	Satellites signal strength, where # - number
status_reg_content	Report status: Trigger content
boot_reason	Boot Reason
bt_rssi_#	Bluetooth RSSI
content	the command response content
inputs	Input’s Status, Bit 1-4: Door button status (1/0 Door Open/Close), Bit 5-8: Tamper button status (1/0 Removal/Installation) 0xff: Failed to get button status
voltage	Voltage degree 0-6: 0: Lowest power and power off 1: No enough power to dial a call or send messages. 2: Low power and alarm 3: Lower power but can work normally 3~6: Work in good condition
wifi_mac_#	WIFI MAC
sea_transport_mode#_1	Sea transportation mode parameter 1, where # - number
hdop	HDOP
sats	Number of satellites
pwr_int	Battery voltage(mV)
battery	Fuel level battery value
wifi_rssi_#	WIFI RSSI
bt_mac_#	Bluetooth MAC
door	Door status
encoding	0X01: UTF-8 0x02: ASCII;
mcc	Mobile Country Code
static_parameter_mode#	Static mode parameter, where # - number
imei	imei number
status_code	Report status: Status code 0x00 Upload in fixed time interval 0x14 Enter Geofence 0x15 Exit Geofence 0x1A Battery low power 0x1B Overspeed
lac	Location Area Code
is_geofence_exit#	Enter or Exit geofence, 1 is enter, 2 is exit, where # - id
iccid	iccid number
rssi	LBS Main Cell Tower, rssi
gps_time_status	GPS is Real Time or Reupload
sensor_type	Sensor type: 0: BLE type; 1: RS485 type.
land_transport_mode#	Land transportation mode, where # - number
sequence_num	Sequence Number
server_flag	It refers to the data to send (by the coding format);
status_trig_time1	Report status: Trigger time
real_time_mode#	Real time current mode, where # - number
alarm	Alarm status: 0: normal 1: SOS 2: Power Cut Alarm 3: Vibration Alarm 4: Fence In Alarm 5: Fence Out Alarm 6: Over-speed Alarm 9: Moving Alarm
imsi	imsi number
sensor_percent	Fuel level in percent
time	Time stamp
temp	Fuel temperature
acc	ACC Status. ACC low: 0, ACC high: 1
sea_transport_mode#_2	Sea transportation mode parameter 2, where # - number
gsm_signal_csq	GSM Signal CSQ
pwr_ext	Voltage level
cell_id#	LBS Auxiliary Cell Tower, cell_idm, where # - number
odometer	Odometer
cell_id	Cell Tower ID
lac#	LBS Auxiliary Cell Tower, lac, where # - number

Nombre del parámetro

Descripción

Unidades de medida

mnc

Mobile Network Code

is_geofence_rectangular#

Circular o rectangular, 0 is circular, 1 is rectangular, where # - id

visible_sats

Visible satellites

battery_vol

Battery Voltage

alarm_status

Alarm status:
0: Normal
1: Shock Alarm
2: Power Cut Alarm
3: Low Battery Alarm
4: SOS

mileage

Mileage statistics

gsm

GSM signal strength degree

sat#_signal_strength

Satellites signal strength, where # - number

status_reg_content

Report status: Trigger content

boot_reason

Boot Reason

bt_rssi_#

Bluetooth RSSI

content

the command response content

inputs

Input’s Status, Bit 1-4: Door button status (1/0 Door Open/Close), Bit 5-8: Tamper button status (1/0 Removal/Installation) 0xff: Failed to get button status

voltage

Voltage degree 0-6:
0: Lowest power and power off
1: No enough power to dial a call or send messages.
2: Low power and alarm
3: Lower power but can work normally
3~6: Work in good condition

wifi_mac_#

WIFI MAC

sea_transport_mode#_1

Sea transportation mode parameter 1, where # - number

hdop

HDOP

sats

Number of satellites

pwr_int

Battery voltage(mV)

battery

Fuel level battery value

wifi_rssi_#

WIFI RSSI

bt_mac_#

Bluetooth MAC

door

Door status

encoding

0X01: UTF-8
0x02: ASCII;

mcc

Mobile Country Code

static_parameter_mode#

Static mode parameter, where # - number

imei

imei number

status_code

Report status: Status code
0x00 Upload in fixed time interval
0x14 Enter Geofence
0x15 Exit Geofence
0x1A Battery low power
0x1B Overspeed

lac

Location Area Code

is_geofence_exit#

Enter or Exit geofence, 1 is enter, 2 is exit, where # - id

iccid

iccid number

rssi

LBS Main Cell Tower, rssi

gps_time_status

GPS is Real Time or Reupload

sensor_type

Sensor type:
0: BLE type;
1: RS485 type.

land_transport_mode#

Land transportation mode, where # - number

sequence_num

Sequence Number

server_flag

It refers to the data to send (by the coding format);

status_trig_time1

Report status: Trigger time

real_time_mode#

Real time current mode, where # - number

alarm

Alarm status:
0: normal
1: SOS
2: Power Cut Alarm
3: Vibration Alarm
4: Fence In Alarm
5: Fence Out Alarm
6: Over-speed Alarm
9: Moving Alarm

imsi

imsi number

sensor_percent

Fuel level in percent

time

Time stamp

temp

Fuel temperature

acc

ACC Status. ACC low: 0, ACC high: 1

sea_transport_mode#_2

Sea transportation mode parameter 2, where # - number

gsm_signal_csq

GSM Signal CSQ

pwr_ext

Voltage level

cell_id#

LBS Auxiliary Cell Tower, cell_idm, where # - number

odometer

Odometer

cell_id

Cell Tower ID

lac#

LBS Auxiliary Cell Tower, lac, where # - number
