Traceur GPS Queclink GL501 LTE | Intégré à Wialon

Afin d'identifier le boîtier Queclink GL501 LTE les détails suivants sont à utiliser dans les réglages de l'unité sur Wialon :

Type du boîtier GPS:	Queclink GL501 LTE
ID unique:	imei

Précisez les paramètres suivants dans le programme de configuration ou dans la configuration Queclink GL501 LTE pour les utiliser dans Wialon Hosting :

Port du serveur:

21948

51 unités Queclink GL501 LTE connectées au le centre de données Wialon — Ça fait 0% de nombre total des boîtiers GPS connectés.

Le diagramme ci-dessous représente la dynamique des connexions dans le centre de données Wialon au cours des 30 derniers jours:

Nom du paramètre	Description	Unités
battery	Current volume of the battery	%
active_mode	Current mode of the device: 0: Power saving mode 1: Continuous nide
movement_status	the movement status of the device 0: Stillness 1: Motion
temp_int	The real time temperature value of the terminal	°С
evt_state1	The light sensor tamper state 0: Normal state 1: Tamper alarm state
iccid	The ICCID of the installed SIM card
csq_rssi	The network signal strength leveel
csq_ber	The quality of the network signal
bt[bt_index]_mask	Bitwise mask to configue which data item is reported bit 0: Bluetooth accessory name bit 1: Bluetooth accessory MAC bit 2: Bluetooth accessory connection status: 1 - connected \| 0 - disconnected bit 3: Bluetooth accessory battery voltage bit 4: Bluetooth accessory temperature bit 5: Bluetooth accessory humidity
bt_num	The number of bluetooth accessory. If it is 0, the accessory details fields from bt_index to bt[bt_index]_hum will not display. I
bt_index	The index of bluetooth accessory. Takes values 0-9
bt[bt_index]_type	The type of the bluetooth accessory. Possible types: 0: No Bluetooth accessory. 6: Beacon temperature/humidity sensor.
bt[bt_index]_raw_data	The data is read from Bluetooth accessory
bt[bt_index]_hum	The humidity data of Bluetooth accessory
bt[bt_index]_temp	The Temperature data of the Bluetooth accessory
bt[bt_index]_bat_level	The battery level of Bluetooth accessory	%
bt[bt_index]_alarm	The alarm type of the bluetooth accessory: 0: The voltage of the Bluetooth accessory is low 1: The temperature alarm: Current temperature value is below low temperature limit 2: The temperature alarm: Current temperature value is upper high temperature limit 3: The temperature alarm: Current temperature value is within the range defined by temperature limit 7: Humidity alarm: Current Humidity value is below low humidity limit 8: Humidity alarm: Current Humidity valueis upper high humidity limit 9: Humidity alarm: Current Humidity values is within the range defined by humidity limit A: The available alarm: The connection status of Bluetooth accessory has changed

Nom du paramètre

Description

Unités

battery

Current volume of the battery

active_mode

Current mode of the device:

0: Power saving mode

1: Continuous nide

movement_status

the movement status of the device

0: Stillness

1: Motion

temp_int

The real time temperature value of the terminal

°С

evt_state1

The light sensor tamper state

0: Normal state

1: Tamper alarm state

iccid

The ICCID of the installed SIM card

csq_rssi

The network signal strength leveel

csq_ber

The quality of the network signal

bt[bt_index]_mask

Bitwise mask to configue which data item is reported

bit 0: Bluetooth accessory name

bit 1: Bluetooth accessory MAC

bit 2: Bluetooth accessory connection status: 1 - connected | 0 - disconnected

bit 3: Bluetooth accessory battery voltage

bit 4: Bluetooth accessory temperature

bit 5: Bluetooth accessory humidity

bt_num

The number of bluetooth accessory. If it is 0, the accessory
details fields from bt_index to bt[bt_index]_hum will not display. I

bt_index

The index of bluetooth accessory. Takes values 0-9

bt[bt_index]_type

The type of the bluetooth accessory. Possible types:

0: No Bluetooth accessory.
6: Beacon temperature/humidity sensor.

bt[bt_index]_raw_data

The data is read from Bluetooth accessory

bt[bt_index]_hum

The humidity data of Bluetooth accessory

bt[bt_index]_temp

The Temperature data of the Bluetooth accessory

bt[bt_index]_bat_level

The battery level of Bluetooth accessory

bt[bt_index]_alarm

The alarm type of the bluetooth accessory:

0: The voltage of the Bluetooth accessory is low

1: The temperature alarm: Current temperature value is below low temperature limit

2: The temperature alarm: Current temperature value is upper high temperature limit

3: The temperature alarm: Current temperature value is within the range defined by temperature limit

7: Humidity alarm: Current Humidity value is below low humidity limit

8: Humidity alarm: Current Humidity valueis upper high humidity limit

9: Humidity alarm: Current Humidity values is within the range defined by humidity limit

A: The available alarm: The connection status of Bluetooth accessory has changed
