Queclink GV57MG

Manufacturer: Queclink Wireless Solutions

Forum Discussion

Number of units

Online

Total

Features Queclink GV57MG:

The following data should also be added to Queclink GV57MG unit properties section of Wialon GPS tracking software :

Device type:	Queclink GV57MG
Unique ID:	imei

Specify the following parameters in configuration software or configuration Queclink GV57MG for use in Wialon Hosting :

Server port:

22168

85 units of Queclink GV57MG device type are connected to Wialon Data Center. This represents 0% of all AVL Hardware connected.

Below chart represents the dynamic of connections in the last 30 days:

Parameter name	Description	Units
battery	The current volume of the backup battery	%
call_number	The phone number of the incoming call which triggers the report message
curr_hour_meter	The current hour meter count	h
curr_mileage	The current mileage	km
ext_gps_ant	External GPS antenna status: 0 - is working 1 - is detected in open circuit state 3 - is in unknown state
h_m_count	The total hour meter count	h
hour_meter_count	The total hour meter count	h
ign	Ignition state: 0 - off, 1 - on
ign_off_duration	Duration since last time the ignition is off	s
ign_on_duration	Duration since last time the ignition is on	s
mileage	The total mileage	km
msg_type	The message ID of HEX format report
pwr_ext	The voltage of the external power supply	V
pwr_int	The voltage of the backup battery. The value of this field is only valid when the external power is not connected	V
report_type	The message type of ASCII format report
motion_state	The current motion state of device: 16 - Tow 1A - Fake Tow 11 - Ignition Off Rest 12 - Ignition Off Motion 21 - Ignition On Rest 22 - Ignition On Motion 41 - Sensor Rest 42 - Sensor Motion
total_hour_meter	The total hour meter count	h
total_mileage	The total mileage	km
total_packets	The total count of the +RESP:GTALM messages
current_packet	The sequence number of the current +RESP:GTALM message
alm	The current configuration of the device from the +RESP:GTALM message
