Queclink GL300A

Manufacturer: Queclink Wireless Solutions

Forum Discussion

Number of units

Online

183

Total

Features Queclink GL300A:

Supported in Wialon:

The following data should also be added to Queclink GL300A unit properties section of Wialon GPS tracking software :

Device type:	Queclink GL300A
Unique ID:	imei

Specify the following parameters in configuration software or configuration Queclink GL300A for use in Wialon Hosting :

Server port:

21715

183 units of Queclink GL300A device type are connected to Wialon Data Center. This represents 0.14% of all Asset trackers connected.

Below chart represents the dynamic of connections in the last 30 days:

Parameter name	Description	Units
report	RESP BUFF ACK
buffer	0 - not buffered message 1 - buffered message	{0,1}
msg_type_name	Name of message type
report_name	GTXXX where XXX is name of message type
proto_ver	Protocol Version
name	Device Name
report_id	Report ID. For GEO: it indicates the ID of the Geo-Fence. For FRI: it indicates the <Append Mask>. For SOS: 0: Triggered through other ways. 1: Triggered by input ID 1. For HBM: “3” indicates high speed, “2” indicates medium speed “1” indicates low speed.
report_type	Report Type. For FRI 0: This message is a common scheduled position report. 1: This message is a turning point. For GEO 0: Exit the corresponding Geo-fence. 1: Enter the corresponding Geo-fence. For SPD 0: Outside the speed range. 1: Inside the speed range. For NMR 0: The state of the device changes from motion to rest. 1: The state of the device changes from rest to motion. For DIS 0: The current logic status of the input port is low level. 1: The current logic status of the input port is high level. For IGL 0: The engine is ignition on. 1: The engine is ignition off. For DOG 0: Reboot periodically according to the <Interval> and <Time> settings or upon ignitionon or by <Input ID> 1: PDP is unable to register successfully or the interaction of messages fails 2: No WCDMA signal For HBM 0: Harsh braking behavior 1: Harsh acceleration behavior
mileage	Mileage
battery	Battery Percentage	0 - 100
temp	Temperature
